ATH6 3P
Full-range current coverage, diverse electrical accessories, strict craftsmanship control, energy-efficient, safe, high-performance and compact.
-
Breaking Capacity
6KA
-
Mechanical Endurance
20000 times
-
Electrical Endurance
10,000 times
-
Entry Manner
Top and bottom
-
Product Certification
CCC，CE，CB，CQC，RoHS
Product Features
Technical Parameters
Main Parameters
|
Rated Current |
1A/2A/4A/6A/10A/16A/20A/25A/32A/40A/50A/63A |
|
Rated Voltage |
1P：230VAC，2P/3P/4P：400VAC |
|
Pole Number |
1P，2P，3P，4P |
|
Analysis Capacity |
6KA |
|
Characteristic / Curve Of Trip |
C/D |
|
Wiring Terminal Tightening Torque |
2.5 Nm max |
|
Function |
Short circuit, overload, disconnect |
|
Wiring Capacity |
With wiring nose: Max. 16mm2 (flexible) / 25mm2 (hard) Without wiring nose: Max. 16mm2 (hard) |
|
Mechanical Endurance |
20000 times |
|
Electrical Endurance |
10,000 times |
|
Pollution Degree |
Ⅱ |
|
Altitude |
2000m |
|
Working Temperature |
Extreme operating temperature -20℃~+55℃ (-5°C to +40°C without capacity reduction) |
|
Storage Temperature |
-20℃~+60℃ |
|
Rated Insulation Voltage |
690V |
|
Rated Surge Withstand Voltage |
4KV |
|
Accessory |
AS/FC auxiliary / alarm contact |
|
Standard |
GB/T 10963.1，IEC 60898-1 |
|
Certification |
CCC，CE，CB，CQC，RoHS |
|
Degree Of Protection |
IP20 |
|
Enclosure Material |
Thermoplastic |
|
Entry Manner |
Top and bottom |
|
Mounting |
Modular structure, DIN rail mountable |
Industry Application
-
New EnergyPromoting the utilization of renewable energy, assisting in the transformation to clean energy
-
MarineAPT products are used to measure,control or indicate the electrical equipment on ships for safety and reliability even in harsh conditions.The products include cam switches, indicators, MCBs, current transformers, etc.
-
Data centerAPT products ensure safe and stable equipment operation in data centers. The products include cam switches,current transformer,MCB,indicators, pushbuttons, relays, etc.
