ALH-0.66 I
Novel design, advanced compensation method, excellent process technology, safe and reliable performance, small and aesthetic appearance, as well as complete varieties, ideal for control, protection, and measurement.
-
Rated Insulation Voltage
AC660V
-
Power Frequency Withstand Voltage
3kV (1min, 50Hz; between the enclosure and secondary terminal)
Product Features
Technical Parameters
Main Parameters
|
Rated Operating Voltage (Un) |
AC660V |
|
Rated Frequency |
50～60Hz |
|
Rated Continuous Thermal Current (Icth) |
1.2 x Ipn |
|
Rated Short Thermal Current (Ith) |
60x Ipn（1sec.） |
|
Power Frequency Withstand Voltage |
3kV (1min, 50Hz; between the enclosure and secondary terminal) |
|
Insulation Class |
E |
|
Type of Wiring Terminal |
Screw pressing sheet fastening type (thread is M4) |
|
Operating Torque |
Tightening torque 0.8～1.2N.m, max. bearing torque 2.4N.m |
|
Degree of Protection |
IP00 for terminal and IP40 for enclosure |
|
Altitude |
Not more than 3,000m |
Industry Application
-
New EnergyPromoting the utilization of renewable energy, assisting in the transformation to clean energy
-
Data centerAPT products ensure safe and stable equipment operation in data centers. The products include cam switches,current transformer,MCB,indicators, pushbuttons, relays, etc.
-
LogisticsAssisting in the intelligence of logistics management systems, improving transportation efficiency and traceability
