ALH-0.66 SK**L
Novel design, advanced compensation method, excellent process technology, safe and reliable performance, small and aesthetic appearance, as well as complete varieties, ideal for control, protection, and measurement.
-
Rated Insulation Voltage
AC660V
-
Power Frequency Withstand Voltage
3kV (1min, 50Hz; between the enclosure and secondary terminal)
-
Wide Range Of Hole Coverage
6mm~46mm
-
Secondary Side Current
2.5mA~60mA
-
Insulation Class
B
Product Features
Technical Parameters
Main Parameters
|
Rated Operating Voltage (Un) |
AC660V |
|
Rated Frequency |
50～60Hz |
|
Power Frequency Withstand Voltage |
3,000V (1min, 50Hz; between the enclosure and secondary terminal) |
|
Insulation Class |
B |
|
Altitude |
≤1,000m (for regular applications: for special applications at altitudes >1,000m, the appropriate transformers must be selected according to the constraints specified in GB20840) |
|
Compliance Standards |
GB20840 |
|
Primary Current |
30A~720A |
|
Secondary Current |
2.5mA~5A |
|
Ambient Temperature for Use |
-25℃~+40℃ |
|
Maximum Temperature Resistance |
120℃ |
|
Ambient Temperature for Storage |
-40℃~+70℃ |
|
Accuracy Grade |
0.5、1 |
