ALS3-PQ-C
13 types of actuator heads, IP67, high mechanical endurance, two types of contact structures, contact combinations of 1NO+1NC and 2NC, anti-release hinge cover design, CCC/CE/RoHS certified
-
Degree of protection
IP67
-
Ambient temperature
-25℃ ~ +70℃
-
Head type
13 types
-
Compatible
Four types of waterproof connectors: M20/M16/Pg11/Pg13.5
-
High mechanical endurance
15,000,000 times
-
Operating frequency
7,200 times per hour
Product Features
Technical Parameters
Main Parameters
|
Rated Insulation Voltage |
AC500V |
|
Power Frequency Withstand Voltage |
AC1890V·50Hz·1min |
|
Rated Thermal Current |
10A |
|
Certificate |
CCC/CE |
|
Mechanical Endurance |
15,000,000 times (7,000,000 times for universal type) |
|
Electrical Endurance |
500,000 times (inductive load) |
|
Ambient Temperature |
-25℃~+70℃ |
|
Ambient Humidity |
<95%RH |
|
Degree of Protection |
IP67 |
|
Action Frequency |
7,200 times/hour (mechanical action frequency) |
|
Anti-impact Class |
30gn·18ms |
|
Anti-vibration Class |
10~55Hz · 0.75mm single amplitude |
|
Contact Material |
Silver alloy |
|
Forced Break Function |
Yes |
